91
F3SG-R
User’s Manual
Chapter2 Setting Zone Adjacency Conditions
System Operation and Functions
E
2-18. Setting Zone Adjacency Conditions
If any two functions of muting, fixed blanking or warning zone functions of the F3SG-RA are used at
the same time, the setting zones have limitations.
This section describes the limitations for following points:
1. Zone adjacent condition: If zones for multiple functions are configured adjacently
2. Zone overlap condition: If zones for multiple functions are configured as overlapped
The muting, fixed blanking and warning zone functions are not available for the F3SG-RE.
1. Zone Adjacency Condition
The table below describes the conditions to configure setting zones for adjacent beams.
Except for some conditions, setting zones for these 3 functions can be located adjacently. The user can make
the setting by the Configuration Tool.
Zone Adjacency Condition
Yes: Possible to configure
* For details about setting adjacent fixed blanking zones.
Refer to Constraint between Fixed Blanking Zones under 2-14. Fixed Blanking.
2. Zone Overlap Condition
The table below describes the conditions to configure setting zones for overlapping beams.
Except for combination of muting zone and fixed blanking zone (figure 3), setting zones of these 3 functions
cannot be overlapped. (Figure 4)
The user can make the setting by the Configuration Tool.
Setting zones of Muting and Floating functions can be overlapped only if each zone covers the full detection zone.
Zone overlap condition
Yes: Possible to configure
No: Not possible to configure
Function Muting Fixed Blanking Warning Zone
Muting - Yes Yes
Fixed Blanking Yes * Yes
Warning Zone Yes Yes -
Function Muting Fixed Blanking Warning Zone
Muting - Yes No
Fixed Blanking Yes No No
Warning Zone No No -
To Next Page
