92
Chapter2 Setting Zone Adjacency Conditions
F3SG-R
User’s Manual
System Operation and Functions
Even if a muting zone and a fixed blanking zone are configured as overlapped, fixed blanking monitoring function is effective.
Muting zone
Fixed blanking zone
Muting zone
Warning zone
Figure 4Figure 3
