100
Chapter2 Designated Beam Output
F3SG-R
User’s Manual
System Operation and Functions
2-22-3. Setting with DIP Switch
The user cannot make any changes to this function by the DIP Switch.
2-22-4. Setting with Configuration Tool
Some settings of functions configurable with the Configuration Tool may increase risks.
Make sure the Responsible Person conduct a thorough risk assessment analysis before
managing and changing the settings. Unintended changes to the settings may cause a
person to go undetected, resulting in serious injury.
The user can make changes to the settings by the Configuration Tool.
If you want to output the light unblocked/blocked states of a designated beam, configure any one of the
output operation mode of auxiliary output or Lamp as designated beam output information.
Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the
Configuration Tool.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information on setting this function by the Configuration Tool.
Function Factory Default Setting Available Parameters
Designated beam output Disable Enable/Disable
Designated beam zone None Any beam
Designated beam state Light-ON Light-ON/Dark-ON
To Next Page
