Omron F3SG series User Manual

31
F3SG-R
User’s Manual
Chapter2 External Test
System Operation and Functions
E
<Timing chart>
2-7-2. Factory Default Setting
The factory default setting is 24 V Active.
2-7-3. Setting with DIP Switch
The user can select the setting from 24 V Active or 0 V Active by the DIP Switch.
Refer to Chapter 3 Setting with DIP Switch for more information on setting this function by the DIP Switch.
2-7-4. Setting with Configuration Tool
The user cannot make any changes to the External Test settings by the Configuration Tool.
TEST
OFF
OSSD
ON
OFF
ON
Toff: ON to OFF Response time
Toff x 4 or less
Toff x 12 or less

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
