Omron F3SG series User Manual

15
F3SG-R
User’s Manual
Chapter1 List of Models
Overview and Specifications
E
1-6. List of Models
1-6-1. List of Models/Response Time/Current Consumption/Weight
F3SG-RA-14
F3SG-RA-30
Model
Number
of
Beams
Protective
Height
[mm]
Response Time[ms]
Current
Consumption
[mA]
Weight
[kg] *3
ON→OFF *1
OFF
(Synchronized)
→ON *2
OFF (Not
synchronized)
→ON *2
Emitter Receiver
F3SG-4RA0160-14 F3SG-2RA0160-14 15 160 8 40 140 40 75 1.8
F3SG-4RA0240-14 F3SG-2RA0240-14 23 240 8 40 140 45 75 2.0
F3SG-4RA0320-14 F3SG-2RA0320-14 31 320 8 40 140 55 75 2.2
F3SG-4RA0400-14 F3SG-2RA0400-14 39 400 8 40 140 60 80 2.7
F3SG-4RA0480-14 F3SG-2RA0480-14 47 480 13 65 165 50 80 2.9
F3SG-4RA0560-14 F3SG-2RA0560-14 55 560 13 65 165 55 80 3.1
F3SG-4RA0640-14 F3SG-2RA0640-14 63 640 13 65 165 60 85 3.3
F3SG-4RA0720-14 F3SG-2RA0720-14 71 720 13 65 165 65 85 3.9
F3SG-4RA0800-14 F3SG-2RA0800-14 79 800 13 65 165 65 90 4.1
F3SG-4RA0880-14 F3SG-2RA0880-14 87 880 13 65 165 70 90 4.3
F3SG-4RA0960-14 F3SG-2RA0960-14 95 960 13 65 165 75 90 4.5
F3SG-4RA1040-14 F3SG-2RA1040-14 103 1040 13 65 165 80 95 4.7
F3SG-4RA1120-14 F3SG-2RA1120-14 111 1120 13 65 165 85 95 4.8
F3SG-4RA1200-14 F3SG-2RA1200-14 119 1200 13 65 165 90 100 5.0
F3SG-4RA1280-14 F3SG-2RA1280-14 127 1280 13 65 165 95 100 5.2
F3SG-4RA1360-14 F3SG-2RA1360-14 135 1360 13 65 165 95 105 5.6
F3SG-4RA1440-14 F3SG-2RA1440-14 143 1440 18 90 190 85 105 5.8
F3SG-4RA1520-14 F3SG-2RA1520-14 151 1520 18 90 190 90 105 6.0
F3SG-4RA1600-14 F3SG-2RA1600-14 159 1600 18 90 190 90 110 6.6
F3SG-4RA1680-14 F3SG-2RA1680-14 167 1680 18 90 190 95 110 6.8
F3SG-4RA1760-14 F3SG-2RA1760-14 175 1760 18 90 190 100 115 7.0
F3SG-4RA1840-14 F3SG-2RA1840-14 183 1840 18 90 190 100 115 7.2
F3SG-4RA1920-14 F3SG-2RA1920-14 191 1920 18 90 190 105 120 7.3
F3SG-4RA2000-14 F3SG-2RA2000-14 199 2000 18 90 190 105 120 7.5
F3SG-4RA2080-14 F3SG-2RA2080-14 207 2080 18 90 190 110 125 8.1
*1.
The response times are values when Scan Code is set at Code B. The response times for Code A are 1 ms shorter than these values.
*2. Refer to 2-3. Optical Synchronization for more information.
*3. The weight includes an emitter, a receiver and included brackets in a product package.
Model
Number
of
Beams
Protective
Height[m
m]
Response Time[ms]
Current
Consumption
[mA]
Weight
[kg] *3
ON→OFF *1
OFF
(Synchronized)
→ON *2
OFF (Not
synchronized)
→ON *2
Emitter Receiver
F3SG-4RA0190-30 F3SG-2RA0190-30 8 190 8 40 140 35 75 1.8
F3SG-4RA0270-30 F3SG-2RA0270-30 12 270 8 40 140 35 75 2.0
F3SG-4RA0350-30 F3SG-2RA0350-30 16 350 8 40 140 40 75 2.2
F3SG-4RA0430-30 F3SG-2RA0430-30 20 430 8 40 140 45 75 2.7
F3SG-4RA0510-30 F3SG-2RA0510-30 24 510 8 40 140 50 75 2.9
F3SG-4RA0590-30 F3SG-2RA0590-30 28 590 8 40 140 50 75 3.1
F3SG-4RA0670-30 F3SG-2RA0670-30 32 670 8 40 140 55 75 3.3
F3SG-4RA0750-30 F3SG-2RA0750-30 36 750 8 40 140 60 80 3.9
F3SG-4RA0830-30 F3SG-2RA0830-30 40 830 8 40 140 65 80 4.0

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
