Omron F3SG series User Manual

16
Chapter1 List of Models
F3SG-R
User’s Manual
Overview and Specifications
F3SG-RE14
F3SG-4RA0910-30 F3SG-2RA0910-30 44 910 13 65 165 50 80 4.2
F3SG-4RA0990-30 F3SG-2RA0990-30 48 990 13 65 165 50 80 4.4
F3SG-4RA1070-30 F3SG-2RA1070-30 52 1070 13 65 165 55 80 4.6
F3SG-4RA1150-30 F3SG-2RA1150-30 56 1150 13 65 165 55 85 4.8
F3SG-4RA1230-30 F3SG-2RA1230-30 60 1230 13 65 165 55 85 4.9
F3SG-4RA1310-30 F3SG-2RA1310-30 64 1310 13 65 165 60 85 5.1
F3SG-4RA1390-30 F3SG-2RA1390-30 68 1390 13 65 165 60 85 5.6
F3SG-4RA1470-30 F3SG-2RA1470-30 72 1470 13 65 165 65 85 5.8
F3SG-4RA1550-30 F3SG-2RA1550-30 76 1550 13 65 165 65 90 6.0
F3SG-4RA1630-30 F3SG-2RA1630-30 80 1630 13 65 165 70 90 6.5
F3SG-4RA1710-30 F3SG-2RA1710-30 84 1710 13 65 165 70 90 6.7
F3SG-4RA1790-30 F3SG-2RA1790-30 88 1790 13 65 165 70 90 6.9
F3SG-4RA1870-30 F3SG-2RA1870-30 92 1870 13 65 165 75 90 7.1
F3SG-4RA1950-30 F3SG-2RA1950-30 96 1950 13 65 165 75 95 7.3
F3SG-4RA2030-30 F3SG-2RA2030-30 100 2030 13 65 165 80 95 7.4
F3SG-4RA2110-30 F3SG-2RA2110-30 104 2110 13 65 165 80 95 8.0
F3SG-4RA2190-30 F3SG-2RA2190-30 108 2190 13 65 165 85 95 8.2
F3SG-4RA2270-30 F3SG-2RA2270-30 112 2270 13 65 165 85 100 8.4
F3SG-4RA2350-30 F3SG-2RA2350-30 116 2350 13 65 165 85 100 8.8
F3SG-4RA2430-30 F3SG-2RA2430-30 120 2430 13 65 165 90 100 8.9
F3SG-4RA2510-30 F3SG-2RA2510-30 124 2510 13 65 165 90 100 9.1
*1.
The response times are values when Scan Code is set at Code B. The response times for Code A are 1 ms shorter than these values.
*2. Refer to 2-3. Optical Synchronization for more information.
*3. The weight includes an emitter, a receiver and included brackets in a product package.
Model
Number
of
Beams
Protective
Height
[mm]
Response Time[ms]
Current
Consumption
[mA]
Weight
[kg] *2
ON→OFF
OFF
(Synchronized)
→ON *1
OFF (Not
synchronized)
→ON *1
Emitter Receiver
F3SG-RE016014 15 160 5 25 125 45 50 1.7
F3SG-RE024014 23 240 5 25 125 55 55 1.9
F3SG-RE032014 31 320 7 35 135 55 55 2.1
F3SG-RE040014 39 400 7 35 135 65 60 2.6
F3SG-RE048014 47 480 7 35 135 70 60 2.8
F3SG-RE056014 55 560 7 35 135 80 60 3.1
F3SG-RE064014 63 640 7 35 135 85 65 3.3
F3SG-RE072014 71 720 9 45 145 80 65 3.8
F3SG-RE080014 79 800 9 45 145 85 70 4.0
F3SG-RE088014 87 880 9 45 145 90 70 4.2
F3SG-RE096014 95 960 9 45 145 95 75 4.4
F3SG-RE104014 103 1040 9 45 145 100 75 4.6
F3SG-RE112014 111 1120 11 55 155 90 75 4.7
F3SG-RE120014 119 1200 11 55 155 95 80 4.9
F3SG-RE128014 127 1280 11 55 155 100 80 5.1
F3SG-RE136014 135 1360 11 55 155 105 85 5.6
F3SG-RE144014 143 1440 11 55 155 110 85 5.7
Model
Number
of
Beams
Protective
Height[m
m]
Response Time[ms]
Current
Consumption
[mA]
Weight
[kg] *3
ON→OFF *1
OFF
(Synchronized)
→ON *2
OFF (Not
synchronized)
→ON *2
Emitter Receiver

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
