Omron F3SG series User Manual

152
Chapter4 Dimensions
F3SG-R
User’s Manual
Wiring/Installation
4-3-3-3. Top/Bottom Adjustable Bracket (F39-LGTB)
4-3-3-4. Top/Bottom Adjustable Bracket (F39-LGTB-1)
4
31
4
48.25
5
26.5
23.2
8.2 6.5 9.5
22.25
44
4 5
18 67
23.5
26
20
161
35
40.8
Top/Bottom
Bracket (1)
Top/Bottom
Bracket (2)
Top/Bottom
Bracket (3)
Screw (2)
Screw(1)
[ Unit : mm ]
Material: SUS304
4
5
°
4
5
°
dia. 20
22.65
18
26
67
23.5
20
5
122
30
3
R1
dia.6
40.8
4- M
4
5
44.25
27
Screw (2)
Top/Bottom
Bracket (1)
Top/Bottom
Bracket (2)
[ Unit : mm ]
Material: SUS304
Note: F39-LGTB-1 does not come with Top/
Bottom Bracket (3) and Screw (1). Refer to
4-4-3-3. Mounting with Top/Bottom
Adjustable Brackets (F39-LGTB) for more
information on parts names of this bracket.
[Reference information]
When you design the joint part with the Top/
Bottom Bracket (2), refer to the drawing
below.
* When you use this bracket with the
Standard Adjustable Bracket (F39-LGA),
the Dimension B must be 27.25 mm.
(dia. 20)
4-47°
4-4.3
dia.15.7
R17
dia. 6.4
8-R2.15
B*

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
