Omron F3SG series User Manual

167
F3SG-R
User’s Manual
Chapter4 Wiring
Wiring/Installation
E
<Internal wiring diagram> (F39-JGB-L)
Twisted pair wires are brown and blue, and white and yellow.
<Internal wiring diagram> (F39-JGB-D)
Twisted pair wires are brown and blue, black and white, yellow and red, and gray and pink.
If the length of the F39-JGA Single-Ended Cable is insufficient, use 1 or more F39-JGB Double-
Ended Cables to extend the length, as required. The total cable extension length of the power cable
must be 100 m max.
<Connection example>
Emitter cable (Gray) Receiver cable (Black) L (m)
F39-JGR5B-L F39-JGR15B-D 0.5
F39-JG1B-L F39-JG1B-D 1
F39-JG3B-L F39-JG3B-D 3
F39-JG5B-L F39-JG5B-D 5
F39-JG7B-L F39-JG7B-D 7
F39-JG10B-L F39-JG10B-D 10
F39-JG15B-L F39-JG15B-D 15
F39-JG20B-L F39-JG20B-D 20
Brown
Blue
Black
White
Yellow
1
3
2
4
5
5
3
21
4
Connected to Power Cable
or Double-Ended Cable
Connected to Single-Ended Cable, or
Double-Ended cable
Brown
Blue
Black
White
Yellow
1
3
2
4
5
Female
5
4
12
3
Male
Brown
Blue
Black
White
Yellow
Red
Gray
Pink
Blue
Black
White
Yellow
Red
Gray
Pink
2
7
5
6
1
8
3
4
Brown
5
8
4
3
2
1
7
6
5
8
6
7
1
2
3
4
2
7
5
6
1
8
3
4
Connected to Power Cable
or Double-Ended Cable
Connected to Single-Ended Cable, or
Double-Ended cable
Female Male
Emitter
Receiver
Cable is gray Model F39-JGB-L(Gray) Model F39-JGA-L(Gray)
Double-Ended Cable
Model F39-JGB
Single-Ended Cable
Model F39-JGA
Cable is black Model F39-JGB-D(Black) Model F39-JGA-D(Black)

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
