Omron F3SG series User Manual

120
Chapter4
F3SG-R
User’s Manual
Wiring/Installation
4-4-3-1. Mounting with Standard Fixed Brackets (F39-LGF)154
4-4-3-2. Mounting with Standard Adjustable Brackets (F39-LGA) 155
4-4-3-3. Mounting with Top/Bottom Adjustable Brackets (F39-
LGTB) 159
4-4-4. Beam Alignment Procedure 162
4-5. Wiring 163
4-5-1. Wiring Precautions 163
4-5-2. Power Supply Unit 164
4-5-3. Cable Connections(F3SG-RA Series) 165
4-5-3-1. Single-Ended Cable 165
4-5-3-2. Double-Ended Cable 166
4-5-3-3. Cascading Cable 168
4-5-3-4. Extending Cable Length with Commercially Available Cable 169
4-5-3-5. Reduced Wiring Connector System with Y-Joint Plug/
Socket Connector 169
4-5-4. Cable Connections(F3SG-RE Series) 173
4-5-4-1. Recommended Cable 173
4-5-4-2. Extending Cable Length with Commercially Available Cable 174
4-5-4-3. Reduced Wiring Connector System 174
4-5-5. Functional Earth Connection 175

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
