Omron F3SG series User Manual

178
Chapter5
F3SG-R
User’s Manual
Input/Output Circuit and Applications
5-2-14. Standalone F3SG-RA with Y-Joint Plug/Socket Connector
using NPN outputs 197
5-2-15. F3SG-RA with Y-Joint Plug/Socket Connector in Standard
Muting Mode/Exit-Only Muting Mode using PNP outputs 198
5-3. Wiring Examples (F3SG-RE Series) 199
5-3-1. Short Mode 199
5-3-2. Long Mode 200
5-3-3. Standalone F3SG-RE with Y-Joint Plug/Socket Connector
201
5-4. Connectable Safety Control Units 202

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
