209
F3SG-R
User’s Manual
Chapter6 Maintenance Checklists
Checklists
E
When muting function setting is changed, a muting sensor must be installed so that muting state
should not occur when a human body enters a hazardous zone of a machine.
When muting function setting is changed, a muting sensor must consist of 2 independent devices.
When the configuration of the cascade connection is changed, either of the following is attached on
a secondary sensor farthest from its power supply:
- End Cap
- Lamp (F39-LP and F39-BTLP, sold separately)
- Bluetooth
®
Communication Unit (F39-BT, sold separately)
When using PNP output, 0 V line of the power supply is grounded. When using NPN output, +24 VDC
line of the power supply is grounded.
Wiring must not be bent, cracked, nor damaged.

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
