Omron F3SG series User Manual

231
F3SG-R
User’s Manual
Chapter7 Glossary
Appendix
E
T Teach-in Function to configure target beams of the following functions by interrupting the
beams.
- Fixed Blanking
- Floating Blanking
Troubleshooting support signal Information to be signaled to the Auxiliary output or Lamp when any one of a
Muting Sequence Error, Interference/Vibration Information and Light Level
Diagnosis Information signals is in the ON state. To signal the information, the
Troubleshooting Support signal must be assigned to an output destination.
U Upper beam(s) Beams located toward the terminal of the F3SG-R.
V Vs Power supply voltage value in your usage environment.
W Warning zone function Function to configure part of the detection zone, in which the Safety outputs
are not affected by the beam state. The blocked state of the Warning zone can
be signaled to the Auxiliary output. This function must not be used for safety
applications.
Warning zone information Information to be signaled to the Auxiliary output or Lamp when the Warning
zone is blocked. To signal the information, the Warning Zone information must
be assigned to an output destination.
Term Description

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
