Omron F3SG series User Manual

70
Chapter2 Muting
F3SG-R
User’s Manual
System Operation and Functions
Refer to 2-24-6. Muting Statistics Information for more information.
Standard Muting Mode
Exit-Only Muting Mode
Position Detection Muting Mode
Dynamic Muting
Make sure the Position 8 of the DIP Switch is set to Configuration Tool Enabled to activate the settings by the
Configuration Tool.
Setting the muting time limit to infinite may cause a failure of the muting sensors to go undetected, resulting in the F3SG-RA
in an unintended muting state. Conduct risk assessment analysis thoroughly before enabling this setting.
Setting the muting input time limit value (maximum) to infinite may cause a failure of the muting sensors to go
undetected, resulting in a failure of disabling the muting state. Conduct risk assessment analysis thoroughly before
enabling this setting.
Dynamic Muting can be used in conjunction with any of Standard, Exit-only and Position detection muting modes.
Refer to Safety Light Curtain Configuration Tool for Model F3SG (SD Manager 2) User’s Manual for more
information on setting this function by the Configuration Tool.
Function Factory Default Setting Available Parameters
Muting zone All beams 1 to all beams in 1-beam increments
T1
min: Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments
T1
max: Muting input time limit value (maximum) 4 s 0.2 to 60 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 20 s in 0.1-s increments
Function Factory Default Setting Available Parameters
Muting zone All beams 1 to all beams in 1-beam increments
T1
min: Muting input time limit value (minimum) 0.1 s 0.1 to 3.9 s in 0.1-s increments
T1
max: Muting input time limit value (maximum) 4 s 0.2 to 60 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 4 s in 0.1-s increments
T4: Muting end wait time 1 s 0.1 to 20 s in 0.1-s increments
T5: Exit-only muting delay time 4 s 4 to 20 s in 0.1-s increments
Function Factory Default Setting Available Parameters
Muting zone All beams 1 to all beams in 1-beam increments
T1
max: Muting input time limit value(maximum) 4 s 0.2 to 60 s in 0.1-s increments, or infinite
T2: Muting time limit 60 s 1 to 600 s in 1-s increments, or infinite
T3: Maximum allowable muting signal interruption 0.1 s 0.1 to 4 s in 0.1-s increments
Function Factory Default Setting Available Parameters
Dynamic muting Disable Enable/Disable
Dynamic muting measurement time 3 s 1 to 25 s in 0.1-s increments
Number of dynamic muting allowable beams 1 0 to 5 in 1-beam increments

Omron F3SG series Specifications

General

Type	Safety Light Curtain
Protection Rating	IP67
Connection	M12 connector
Detection Method	Infrared Light
Operating Temperature	-10°C to +55°C
Resolution	14mm, 25mm, 40mm
Standards	EN/IEC 61496-1, EN ISO 13849-1
Power Supply Voltage	24V DC ±10%
