Panasonic FP0R - Power Supply Unit; Options; Repair Parts

1-6
1.1.4 Power Supply Unit
Product name
Specifications
Part No.
Product No.
FP0 Power supply unit
Input voltage: 100 to 240 V AC Free input
Output capacity: 0.7A, 24 V DC
FP0-PSA4 AFP0634
1.1.5 Options
Product name
Specifications
Product No.
FP Memory loader
Programming tool for copying programs written to
control unit
Data clear type AFP8670
Data hold type
AFP8671
FP0
Mounting
plate
Slim type
Mounting plate for mounting control unit or expansion unit on a panel
vertically.
AFP0803 (10-pack)
Flat type
Mounting plate for mounting Control unit on a panel horizontally.
AFP0804 (10-pack)
Wiring tools
Terminal
screwdriver
Required for connecting the terminal block (made by Phoenix Contact
Co.) supplied with the relay output terminal type.
AFP0806
Molex
connector
pressure
contact tool
Required for connecting the connector supplied with the relay output type
Molex connector. Equivalent to Molex Product No.: 57189-500.
AFP0805
Multi-wire
connector
pressure
contact tool
Required for connecting the connector supplied with the transistor output
type.
AXY52000FP
Options for
wiring
Relay
output
Molex type
I/O cable
Loose-wiring cable, with Molex socket attached at one
end. 9 P.
AWG20 (0.5mm
2
), 2 pcs (blue and white) /set.
Length: 1 m
AFP0551 (2 cable set)
Length: 3 m AFP0553 (2 cable set)
Transistor
output type
I/O cable
Loose-wiring cable, with connector attached at one end.
10P.
AWG22 (0.3mm
2
), 2 pcs (blue and white) /set.
Length: 1 m AFP0521 (2 cable set)
Length: 3 m AFP0523 (2 cable set)
Flat cable
connector
for transistor
output type.
Required for wiring with flat cables. 10P. AFP0808 (4-pack )
1.1.6 Repair Parts
Product name Specifications Product No.
Terminal socket Attaches to relay output and terminal block type. Maintenance parts AFP0802(2 cable set)
Molex socket
Attaches to relay output and Molex connector type. Maintenance parts
AFP0801(2 cable set)
Wire-press socket Attaches to transistor output type. Maintenance parts AFP0807(2 cable set)
Wire-press contact For transistor output type unit.
Suitable wire: AWG #22 / AWG
#24
AXW7221FP
(5 pins in line)
Suitable wire: AWG #26 / AWG
#28
AXW7231FP
(5 pins in line)
FP0R/FPΣ Power supply
cable
Attaches to FP0R control unit. Maintenance parts. Length: 1m AFPG805 (1-pack)
FP0 Power supply cable Attaches to FP0 various units. Maintenance parts Length: 1m AFP0581(1-pack)
Note) Order wire-press contacts in units of 200 pins in 40 rows.
