4.2 I/O Allocation for FP0R Control Unit
4.2.1 I/O Numbers of FP0R Control Unit
The I/O allocation of FP0R control unit is fixed.
Type of control unit
Number of allocation
I/O number
C10
Input (6 point)
X0 to X5
Output (4 points) Y0 to Y3
C14
Input (8 points) X0 to X7
Output (6 points)
Y0 to Y5
C16
Input (8 points)
X0 to X7
Output (8 points) Y0 to Y7
C32/T32/F32
Input (16 points) X0 to XF
Output (16 points)
Y0 to YF
