Panasonic FP0R - Table of Specifications

13-2
13.1 Table of Specifications
13.1.1 General Specifications
Item
Description
Rated operating voltage 24 V DC
Operating voltage range
20.4 to 28.8 V DC
Allowable momentary
power off time
C10, C14, C16: 5 ms(at 20.4 V), 10 ms(at 21.6 V)
C32, T32, F32 : 10 ms(at 20.4 V)
Fuse Built-in (Not replaceable)
Ambient temperature
0 to +55
°
C
Storage temperature -40 to +70 °C (T32 only: -20 to +70 °C)
Ambient humidity
10 to 95 % RH (at 25
°
C, No condensation)
Storage humidity 10 to 95 % RH (at 25 °C, No condensation)
Breakdown voltage
(Detection current: 5 mA)
Tr output type
Ry output type
Between “input terminals” and “output
terminals”
500 V AC
for 1 minute
1500 V AC
for 1 minute
Between “output terminals” and “output
terminals” (Between different commons)
-
1500 V AC
for 1 minute
Between “input terminals” and “power/ground
terminals”
500 V AC
for 1 minute
500 V AC
for 1 minute
Between “output terminals” and
“power/ground terminals”
500 V AC
for 1 minute
1500 V AC
for 1 minute
Between “ground terminal” and “power
terminal”
500 V AC
for 1 minute
500 V AC
for 1 minute
Insulation resistance
(Test voltage: 500 V DC)
Tr output type Ry output type
Between “input terminals” and “output
terminals”
Over 100 MΩ Over 100 MΩ
Between “output terminals” and “output
terminals” (Between different commons)
- Over 100 MΩ
Between “input terminals” and “power/ground
terminals”
Over 100 MΩ Over 100 MΩ
Between “output terminals” and
“power/ground terminals”
Over 100 MΩ Over 100 MΩ
Between “ground terminals” and “power
terminal”
Over 100 MΩ Over 100 MΩ
Vibration resistance
5 to 9 Hz, Single amplitude of 3.5 mm, 1 sweep/min.,
9 to 150 Hz, Constant acceleration of 9.3 m/s
2
, 1 sweep/min.,
10 min. on 3 axes (Towards X,Y & Z directions)
Shock resistance
147 m/s
2
, 4 times on 3 axes (Towards X,Y & Z directions)
Noise immunity
1000 V[P-P] with pulse width 50 ns, 1μs (using a noise simulator)
(Power supply terminal)
Operating condition
Must be free from corrosive gases and excessive dust
Overvoltage category Category II
Pollution level
Pollution level 2
Weight
C10:100g, C14:105g, C16:85g, C32:115g, T32:120g, F32:115g
E16T/P, E16X : 65g, E16YT/P: 70g, E32T/P: 80g, E8X: 60g, E8YT/P: 60g,
E8RS/M: 90g, E16RS/M: 100g, E8YRS: 95g
