Panasonic FP0R - Power Supply Unit and IO Link Unit Specifications

13-11
13.4 Power Supply Unit and I/O Link Unit Specifications
13.4.1 Power Supply Unit Specifications (AFP0634)
Item
Description
Input Rated operating voltage 100-240 V AC
Operating voltage range
85-264 V AC
Rated frequency 50/60 Hz
Operating frequency
47 to 63 Hz
The number of phase Single phase
Inrush current
30 A(0-p) or less (Cold start)
Leakage current 0.75 mA or less
Holding time
10 ms or more
Output Rated voltage 24 V DC
Voltage accuracy
±
5%
Rated current 0.7 A
Operating output current
0 to 0.7 A
Output ripple 500 mV or less
Over current regulation
0.735 A or more
Over voltage regulation Possible
Life time
20000h ( at 55
°
C)
13.4.2 I/O Link Unit Specifications (AFP0732)
Item
Description
Communication method
Two-wire half-duplex communication
Synchronous method Start stop synchronous system
Transmission line
Duplex cable (twisted-pair cable or
VCTF 0.75 mm2 x 2C <JIS> or equivalent)
Transmission distance (Total length)
Max. 700 m (when using twisted-pair cable)
Max. 400 m (when using VCTF cable)
Baud rate
0.5Mbps
No. of I/O points per one I/O link unit 64 points (Input: 32 points + Output: 32 points)
Note)
Remote I/O map allocation
32X/32Y
Interface RS485-compliant
Transmission error check
CRC method
Note) Those numbers of points are the numbers that can be used for I/O link via a host computer and
the network MEWNET-F. When setting the output of the I/O link error flag to ON (available), it is 63
points (31 input points & 32 input points).
