4.3 I/O Numbers of FP0/FP0R Expansion Unit
- I/O numbers do not need to be set as I/O allocation is automatically performed when an expansion unit
is added.
- The I/O allocation of expansion unit is determined by the installation location.
Type of unit
Number of
allocation
Expansion
unit 1
Expansion
unit 2
Expansion
unit 3
FP0/FP0R
Expansion unit
E8X
Input (8 points)
X20 to X27
X40 to X47
X60 to X67
E8R
Input (4 points) X20 to X23 X40 to X43 X60 to X63
Output (4 points) Y20 to Y23 Y40 to Y43 Y60 to Y63
E8YT/P
E8YR
Output (8 points) Y20 to Y27 Y40 to Y47 Y60 to Y67
E16X
Input (16 points)
X20 to X2F
X40 to X4F
X60 to X6F
E16R
E16T/P
Input (8 points) X20 to X27 X40 to X47 X60 to X67
Output (8 points) Y20 to Y27 Y40 to Y47 Y60 to Y67
E16YT/P
Output (16 points)
Y20 to Y2F
Y40 to Y4F
Y60 to Y6F
E32T/P
Input (16 points)
X20 to X2F
X40 to X4F
X60 to X6F
Output (16 points) Y20 to Y2F Y40 to Y4F Y60 to Y6F
FP0 Analog I/O
unit
FP0-A21
Input (16 points)
CH0
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input (16 points)
CH1
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
Output (16 points)
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
FP0 A/D
conversion unit
FP0 Thermocouple
unit
FP0-A80
FP0-TC4
FP0-TC8
Input (16 points)
CH0, 2, 4, 6
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input (16 points)
CH1, 3, 5, 7
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
FP0 RTD unit FP0-RTD
Input (16 points)
CH0, 2, 4
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Input (16 points)
CH1, 3, 5
WX3
(X30 to X3F)
WX5
(X50 to X5F)
WX7
(X70 to X7F)
Output (16 points)
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
FP0 D/A
conversion unit
FP0-A04V
FP0-A04I
Input (16 points)
WX2
(X20 to X2F)
WX4
(X40 to X4F)
WX6
(X60 to X6F)
Output (16 points)
CH0, 2
WY2
(Y20 to Y2F)
WY4
(Y40 to Y4F)
WY6
(Y60 to Y6F)
Output (16 points)
CH1, 3
WY3
(Y30 to Y3F)
WY5
(Y50 to Y5F)
WY7
(Y70 to Y7F)
FP0 I/O link unit FP0-IOL
Input (32 points) X20 to X3F X40 to X5F X60 to X7F
Output (32 points) Y20 to Y3F Y40 to Y5F Y60 to Y7F
- The data for the each channels of FP0 A/D conversion unit (FP0-A80), FP0 thermocouple unit (FP0-
TC4/FP0-TC8) and FP0 D/A conversion unit (FP0-A04V/FP0-A04I) is converted and loaded with a user
program that includes a switching flag to convert the data.
- Regarding FP0 CC-Link slave unit, please refer to the exclusive manual.
