Panasonic FP0R - Type of Computer and Suitable Cable; D-Sub Connector Cable; USB Cable

1-9
Type of computer and suitable cable
For the connection between a personal computer (RS232C) and the control unit (RS232C)
D-sub connector cable
PLC side
connector
PLC side connector Specifications Product No.
D-sub 9-pin
Female-Mini DIN round 5-pin L type (3 m) AFC8503
Female-Mini DIN round 5-pin Straight type (3 m) AFC8503S
Note) A USB/RS232C conversion cable is necessary to connect with a personal computer without a
serial port using a PC connection cable.
For the connection between a personal computer (USB) and the control unit (USB)
USB cable
Use a commercial cable.
Cable type
Length
USB 2.0 cable (A: miniB)
Max. 5 m
Note) Windows2000 or later OS is required for the communication with a USB.
