Panasonic FP0R - Intelligent Units; Link Units

1-5
1.1.2 Intelligent Units
Product name Specifications Part No.
Product
No.
Exclusive
manual
FP0 Analog I/O unit
<Input specifications>
No. of channels: 2 channels
Input range: Voltage: 0 to 5 V,
-10~+10V (Resolution: 1/4000)
Current: 0 to 20 mA (Resolution: 1/4000)
FP0-A21 AFP0480 ARCT1F390
<Output specifications>
No. of channels: 1 channel
Output range: Voltage: -10 to +10 V (Resolution: 1/4000)
Current: 0 to 20 mA (Resolution: 1/4000)
FP0 A/D Converter
unit
<Input specifications>
No. of channels: 8 channels
Input range: Voltage: 0 to 5 V, -10 to +10V, -100 to 100 mV
(Resolution: 1/4000)
Current: 0 to 20 mA (Resolution: 1/4000)
FP0-A80 AFP0401 ARCT1F321
FP0 Thermocouple
unit
K, J, T, R thermocouples, resolution: 0.1°
C
FP0-TC4 AFP0420
ARCT1F366
K, J, T, R thermocouples, resolution: 0.1
°
C
FP0-TC8
AFP0421
FP0 RTD
(Resistance-
temperature detector)
unit
Pt100, Pt1000,Ni1000
Resolution: 0.1
°C /0.01°C (Switch type)
FP0-RTD6 AFP0430 ARCT1F445
FP0 D/A Converter
unit
<Output specifications>
No. of channels: 4 channels
Output range: (Voltage output type): -10 to +10 V
(Resolution: 1/4000)
(Current output type): 4 to 20 mA (Resolution: 1/4000)
FP0-A04V AFP04121
ARCT1F382
FP0-A04I AFP04123
1.1.3 Link Units
Product name Specifications
Power
supply
voltage
Part No.
Product
No.
Exclusive
manual
FP0 I/O Link Unit
This is a link unit designed to make the FP0R
function as a slave unit to MEWNET-F (remote
I/O system).
24V DC
FP0-IOL
AFP0732 This manual
FP0 CC-Link
Slave unit
This unit is for making the FP0R function as a
slave unit of the CC-Link.
Only one unit can be connected to the furthest
right edge of the FP0 expansion bus.
Note) Accuracy will change if an FP0
thermocouple unit is used at the same time.
24V DC
FP0-
CCLS
AFP07943 ARCT1F380
C-NET Adapter
S2 type
(for PLC side)
This is an RS485 adapter designed to allow use
of the computer link function for connecting to a
host computer via C-NET. With PLC tool port
cable (30 cm). A power supply is not required.
- - AFP15402
ARCT1F96
C-NET Adapter
(for computer side)
This is an RS485 adapter designed to allow use
of the computer link function for connecting to a
network-connected PLC via C-NET from a host
computer.
100 to
240V AC
- AFP8536
24V DC - AFP8532
FP Web-Server2
unit
Connected with FP series PLCs, it conducts Ethernet
communication, sends e-mail, and displays the PLC data on
HTML pages.
FP-
WEB2
AFP0611 ARCT1F446
