Panasonic FP0R - IO Number Allocation

13-8
13.2 I/O Number Allocation
13.2.1 I/O Numbers for FP0R Control Unit
The I/O allocation for the FP0R control unit is fixed.
Unit type
Allocation points
I/O No.
C10
Input: 6 points X0 to X5
Output: 4 points
Y0 to Y3
C14
Input: 8 points X0 to X7
Output: 6 points
Y0 to Y5
C16
Input: 8 points X0 to X7
Output: 8 points
Y0 to Y7
C32/T32/F32
Input: 16 points X0 to XF
Output: 16 points
Y0 to YF
