15.3 Table of High-level Instructions
The high-level instructions are expressed by the prefixes “F” or “P” with numbers. For most of the high-level
instructions, “F” and “P” types are available. The differences between the two types are explained as follows:
- Instructions with the prefix “F” are executed in every scan while its trigger is in the on.
- Instructions with the prefix “P” are executed only when the leading edge of its trigger is detected.
For the FP0/FP0R/FPΣ/FP-X, the P type high-level instructions are not available.
Num-
ber
Name
Boo-
lean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP2
FP2SH/FP10SH
Data transfer instructions
F0
P0
16-bit data
move
MV
PMV
S, D
(S)→(D)
5
F1
P1
32-bit data
move
DMV
PDMV
S, D
(S+1, S)→(D+1, D)
7
F2
P2
16-bit data
invert and
move
MV
PMV/
S, D
(S)→(D) 5
F3
P3
32-bit data
invert and
move
DMV/
PDMV/
S, D
(S+1, S)→(D+1, D) 7
F4
P4
Reading of
head word
No. of the
specified slot
GETS
PGETS
S, D
The head word No. of the specified slot is
read.
5
*1 *1
F5
P5
Bit data
move
BTM
PBTM
S, n,
D
The specified one bit in “S” is transferred to
the specified one bit in “D”. The bit is
specified by “n”.
7
F6
P6
Hexadecimal
digit (4-bit)
data move
DGT
PDGT
S, n, d
The specified one digit in “S” is transferred
to the specified one digit in “D”. The digit is
specified by “n”.
7
F7
P7
Two 16-bit
data move
MV2
PMV2
S1,
S2, D
(S1)→(D),
(S2)
→
(D+1)
7
F8
P8
Two 32-bit
data move
DMV2
PDMV2
S1,
S2, D
(S1+1, S1)→(D+1, D),
(S2+1, S2)
→
(D+3, D+2)
11
F10
P10
Block move
BKMV
PBKMV
S1,
S2, D
The data between “S1” and “S2” is
transferred to the area starting at “D”.
7
F11
P11
Block copy
COPY
PCOPY
S, D1,
D2
The data of “S” is transferred to the all area
between “D1” and “D2”.
7
F12
Data read
from EEP-
ROM
ICRD
S1,
S2, D
The data stored in the expansion memory
of the EEP-ROM specified by “S1” and “S2”
are transferred to the area starting at “D”.
11
*2
P13
Data write to
EEP-ROM
PICWT
S1,
S2, D
The data specified by “S1” and “S2” are
transferred to the EEP-ROM starting at “D”.
11
*2
F12
Data read
from F-ROM
ICRD
S1,
S2, D
The data stored in the expansion memory
of the F-ROM specified by “S1” and “S2”
are transferred to the area starting at “D”.
11
P13
Data write to
F-ROM
PICWT
S1,
S2, D
The data specified by “S1” and “S2” are
transferred to the F-ROM starting at “D”.
11
F12
P12
Data read
from IC card
ICRD
PICRD
S1,
S2, D
The data stored in the expansion memory
of the IC card specified by “S1” and “S2”
are transferred to the area starting at “D”.
11
F13
P13
Data write to
IC card
ICWT
PICWT
S1,
S2, D
The data specified by “S1” and “S2” are
transferred to the IC card expansion
memory area starting at “D”.
11
F14
P14
Program read
from IC
memory card
PGRD
PPGRD
S
The program specified using “S” is
transferred into the CPU from IC memory
card and executes it.
3
: Available, : Not available, : Not available partially
*1) This instruction is available for FP2/FP2SH Ver. 1.5 or later.FP10SH cannot be used
*2) This instruction is available for FP0 Ver. 2.0 or later and FP-e.
