Panasonic FP0R - Communication Specifications

7-5
7.3 Communication Specifications
Tool Port
Description
Interface
RS232C
Transmission distance 15 m
Baud rate 2400,4800,9600,19200,38400,57600,115200 bit/s
Communication method
Half-duplex communication
Synchronous method
Start stop synchronous system
Communication format
Data length: 7 bits/8bits
Parity: None/Even/Odd
Start code: STX/No STX
End code: CR/CR+LF/None/ETX
Stop bit: 1 bit/2 bits
Data transmission order Transmits from bit 0 character by character.
Communication mode
Computer link (slave)
Modem initialization
General-purpose communication (only in RUN mode)
USB port
Description
Standard (Baud rate) USB2.0 Fullspeed
Communication mode
Computer link (slave)
COM port (RS232C port)
Description
Interface RS232C
Transmission distance
15 m
Baud rate
2400,4800,9600,19200,38400,57600,115200 bit/s
Communication method Half-duplex communication
Synchronous method Start stop synchronous system
Communication format
Data length: 7 bits/8bits
Parity: None/Even/Odd
Start code: STX/No STX
End code: CR/CR+LF/None/ETX
Stop bit: 1 bit/2 bits
Data transmission order
Transmits from bit 0 character by character.
Communication mode
Computer link (master/slave)
Modem initialization
General-purpose communication
MODBUS RTU (master/slave)
PC(PLC) link
Factory default settings
Baud rate
Data length
Parity
Stop bit
Tool port
9600 bit/s
8 bits
Odd
1 bit
COM port (RS232C port) 9600 bit/s 8 bits Odd 1 bit
