3.2 Part Names and Functions
Expansion Units
Part Names and Functions
Power supply connector
Supply 24 V DC. It is connected using the cable (AFP0581) supplied with the unit.
Input connector
Input indicator LED
Output connector
Output indicator LEDs
Expansion hook
This hook is used to secure expansion units.
Expansion connector
This connector is used to connect an expansion unit and internal circuit.
DIN hook
This hook enables the unit to attach to a rail at a touch. It is also used to install the unit on the slim type mounting
plate (AFP0803).
