5.1 Installation
5.1.1 Installation Environment and Space
Operating environment
(Use the unit within the range of the general specifications when installing)
- Ambient temperature: 0 to +55 °C
- Ambient humidity: 10 to 95 % RH (at 25 °C, non-condensing)
- For use in pollution Degree 2 environment.
- Do not use the unit in the following environments.
- Direct sunlight
- Sudden temperature changes causing condensation.
- Inflammable or corrosive gas.
- Excessive airborne dust, metal particles or saline matter.
- Benzine, paint thinner, alcohol or other organic solvents or strong alkaline solutions such as ammonia
or caustic soda.
- Direct vibration, shock or direct drop of water.
- Influence from power transmission lines, high voltage equipment, power cables, power equipment,
radio transmitters, or any other equipment that would generate high switching surges.(100 mm or
more)
Static electricity
- Do not touch connector pins directly to prevent static electricity from causing damage.
- Always rid yourself of any static electricity before handling this product.
Measures regarding heat discharge
Always install the unit oriented with the tool port facing outward on the bottom in order to prevent the
generation of heat.
- Do not install the unit as shown below.
- Do not install the unit above devices which generate heat such heaters, transformers or large scale
resistors.
