Panasonic FP0R - Page 245

13-3
Unit’s current consumption table
Control unit
current
consumption
Expansion
unit current
consumption
Input circuit
current
consumption
Output circuit
current
consumption
This is the current
consumed from
the control unit
power supply
connector. If
expansion units or
intelligent units are
added, the current
is increased by the
value indicated
below.
This is the
current
consumed from
the expansion
unit power
supply
connector. If a
unit is not listed
below, it means
that it has no
power supply
connector
This is the
current
consumed by the
input circuits of
the various units.
This value
indicates the
current that flows
into the input
circuit.
This is the current
consumed by the
output circuits of
the various units.
This value
indicates the
current used to
drive the output
circuits. This value
does not include
the load current
value.
FP0R
control unit
FP0R-C10 100 mA or less − 15.9 mA or less −
FP0R-C14
120 mA or less
−
21.1 mA or less
−
FP0R-C16 70 mA or less − 21.1 mA or less 20 mA or less
FP0R-C32
FP0R-T32
FP0R-F32
90 mA or less − 42.2 mA or less 40 mA or less
FP0/FP0R
expansion
unit
FP0-E8X 10 mA or less 37.6 mA or less −
FP0-E8R
10 mA or less
50 mA or less
18.8 mA or less
−
FP0-E8YR 10 mA or less 100 mA or less − −
FP0-E8YT/P
15 mA or less
− −
26 mA or less
FP0-E16X 10 mA or less − 75.2 mA or less −
FP0-E16R
20 mA or less
100 mA or less
37.6 mA or less
−
FP0-E16T/P 20 mA or less − 37.6 ma or less 26 mA or less
FP0-E16YT/P
25 mA or less
− −
52 mA or less
FP0-E32T/P 35 mA or less − 75.2 mA or less 52 mA or less
FP0
intelligent
unit
FP0-A21
20 mA or less
100 mA or less
− −
FP0-A80 20 mA or less 60 mA or less − −
FP0-A04V
20 mA or less
100 mA or less
− −
FP0-A04I 20 mA or less 130 mA or less − −
FP0-TC4
FP0-TC8
FP0-RTD6
25 mA or less − − −
FP0-IOL 30 mA or less 40 mA or less − −
FP0-CCLS
40 mA or less
40 mA or less
− −
Programmable display
(5 VDC, RS232C type)
80 mA or less − − −
C-NET
adapter S2
AFP15402 50 mA or less − − −
