9-10
9.3.2 Setting Method
Setting with FPWIN GR
1. Select "Online" > "Online Edit Mode" in the menu bar, and press the CTRL and F2 keys.
The screen is switched to "Online Monitor".
2. Select "Tool" > "Set PLC Password" in the menu bar.
The "Set PLC Password" dialog box is displayed.
3. Set the items in the table below, and click on the “Settings” button.
8 digits password Enter a 8-digit password.
Setting of FP memory loader option
Check the box of the function to use.
- Limited distribution function
→ "Allow the download in case of same password"
- Enable the upload protection setting.
→
"Set that PLC cannot be uploaded"
Note:
This function is available only when a 8-digit password has been set.
To Next Page
