15-19
WR910 FP0R
Relay
No.
Name Description
R9110
High-speed
counter
control flag
HSC-CH0
- Turns on the channel of high-speed counter during the
control using F165(CAM0), F166(HC1S), F167(HC1R),
F178(PLSM) instructions.
- Turns off when the control is cleared or this instruction is
completed.
R9111
HSC-CH1
R9112
HSC-CH2
R9113
HSC-CH3
R9114
HSC-CH4
R9115
HSC-CH5
R9116 to
R911F
Not used
R9120
Pulse output
instruction
flag
PLS-CH0
- Turns on while the pulses are being output using
F171(SPDH), F172 (PLSH), F173(PWMH), F174 (SP0H),
F175(SPSH), F177(HOME) instructions.
R9121
PLS-CH1
R9122
PLS-CH2
R9123
PLS-CH3
R9124 to
R912F
Not used
R9130
Pulse output
control flag
PLS-CH0
- Turns on the channel of pulse output during the control
using F166(HC1S), F167(HC1R) instructions.
- Turns off when the control is cleared or this instruction is
completed.
R9131
PLS-CH1
R9132
PLS-CH2
R9133
PLS-CH3
R9134 to
R913F
Not used
A: Available, N/A: Not available
