15-61
Num-
ber
Name Boolean
Ope-
rand
Description
Steps
FP0/FP-e
FP0R
FP
Σ
FP-X
FP2
FP2SH/FP10SH
Integer type data processing instructions
F270
P270
Maximum
value (word
data (16-bit))
MAX
PMAX
S1,
S2, D
Searches the maximum value in the
word data table between the “S1” and
“S2”, and stores it in the “D”. The
address relative to “S1” is stored in
“D+1”.
8
*1
F271
P271
Maximum
value (double
word data (32-
bit))
DMAX
PDMAX
S1,
S2, D
Searches for the maximum value in
the double word data table between
the area selected with “S1” and “S2”,
and stores it in the “D”. The address
relative to “S1” is stored in “D+2”.
8
*1
F272
P272
Minimum value
(word data (16-
bit))
MIN
PMIN
S1,
S2, D
Searches for the minimum value in
the word data table between the area
selected with “S1” and “S2”, and
stores it in the “D”. The address
relative to “S1” is stored in “D+1”.
8
*1
F273
P273
Minimum value
(double word
data (32-bit))
DMIN
PDMIN
S1,
S2, D
Searches for the minimum value in
the double word data table between
the area selected with “S1” and “S2”,
and stores it in the “D”. The address
relative to “S1” is stored in “D+2”.
8
*1
F275
P275
Total and
mean values
(word data (16-
bit))
MEAN
PMEAN
S1,
S2, D
The total value and the mean value of
the word data with sign from the area
selected with “S1” to “S2” are
obtained and stored in the “D”.
8
*1
F276
P276
Total and
mean values
(double word
data (32-bit))
DMEAN
PDMEAN
S1,
S2, D
The total value and the mean value of
the double word data with sign from
the area selected with “S1” to “S2”
are obtained and stored in the “D”.
8
*1
F277
P277
Sort (word
data (16-bit))
SORT
PSORT
S1,
S2,
S3
The word data with sign from the
area specified by “S1” to “S2” are
sorted in ascending order (the
smallest word is first) or descending
order (the largest word is first).
8
*1
F278
P278
Sort (double
word data (32-
bit))
DSORT
PDSORT
S1,
S2,
S3
The double word data with sign from
the area specified by “S1” to “S2” are
sorted in ascending order (the
smallest word is first) or descending
order (the largest word is first).
8
*1
F282
P282
Scaling of
16-bit data
SCAL
PSCAL
S1,
S2, D
The output value Y is found for the
input value X by performing scaling
for the given data table.
8
*1
F283
P283
Scaling of
32-bit data
DSCAL
PDSCAL
S1,
S2, D
The output value Y is found for the
input value X by performing scaling
for the given data table.
10
F284
P284
Inclination
output of 16-bit
data
RAMP S1,
S2,
S3, D
Executes the linear output for the
specified time from the specified
initial value to the target value.
10
*2 *2
Integer type non-linear function instructions
F285
P285
Upper and
lower limit
control
(16-bit data)
LIMT
PLIMT
S1,
S2,
S3, D
When S1>S3, S1→D
When S1<S3, S2→D
When S1<or = S3<or = S2, S3→D
10
*1
: Available, : Not available, : Not available partially
*1) This instruction is only available for FP-e Ver.1.2 or later.
*2) This instruction is only available for FP-X Ver.2.0 or later, and FPΣ Ver. 3.10 or later.
