88 Configuration Tab
Logical Tab
The Logical Tab pane describes the configuration of a logical library and shows the logical element
properties. The starting Logical pane shows the properties of Scalar DLC host PC.
Figure 60 Logical Controller
Selecting the Controller causes the Scalar DLC host PC property list to appear.
Field/Button Icon Operation Description
CPU Identifier Supplied The CPU identifier
CPU Vendor ID Supplied The CPU vendor identifier
CPU Speed Supplied The CPU speed
Total Physical Memory Supplied The total physical memory size
Free Physical Memory Supplied The free physical memory size
Total Virtual Memory Supplied The total virtual memory size
Free Virtual Memory Supplied The free virtual memory size
Add new Logical Library Click The pop-up window of logical library creation
appears. Refer to C
reate Library on page 107.
Help Click Open online help for the current pane.
