Scalar DLC Reference Guide 91
Resource
Figure 62 Logical Library Resources
The resource charts show the total coverage of the logical library. For example, if the physical library
contains 1000 storage slots, and the configured logical library covers 800 slots, the Storage chart shows
80%. Same for the Mailbox (I/E), Drives, and Cartridges.
Field/Button Icon Operation Description
Storage Supplied Storage slots usage, % and chart.
I/E slots Supplied Insert/eject slots usage, % and chart.
Drives Supplied Drives usage, % and chart.
Cartridges Supplied Cartridges usage, % and chart.
Refresh Click Refresh Logical Library resources.
Help Click Open online help for the current pane.
