Scalar DLC Reference Guide 37
Accept the default name or enter the desired name. ADIC recommends accepting the default name while
being sure not to duplicate an existing client name.
The next dialog is Configuration Summary. See figure below.
Figure 20 Configuration Summary
Name Operation Description
Select the
type of new
Client
Select DAS Client creates the DAS client with all parameters by default.
Always available if the DAS Client support is installed.
SCSI Client creates the SCSI Client assigned to the first free LUN of
the first existing Target. Available only after the SCSI is configured (at
least one target is created and at least one LUN is free). Refer to
C
reate Target on page 169 and Create LUN on page 170.
ROBAR Client selects the ROBAR Client. Available only after the
ROBAR interface is configured (non-zero port is specified). Refer to
ROBAR
on page 156.
Name of new
Client
Enter Enter the name of the new client.
Name Operation Description
Summary Supplied Be sure that the data entered from the previous dialogs is correct.
