120 Configuration Tab
Figure 88 Physical Partition
Field/Button Icon Operation Description
Name Enter Partition name. Should be unique throughout all physical
libraries.
Also refer to Table 6
on page 16.
Element
class
Supplied Partition class (storage, I/E, drive). See Table 13
on page 65.
Element type Supplied Partition element type. Refer to S
torage Types on page 247,
Mailbox Type
s on page 248, or Drive Types on page 249.
Start Supplied Start element of partition range.
End Supplied End element of partition range.
Allocation Supplied Robot1 / Robot2 indicates the robotic device where the
partition is located.
Shared means the partition is shared between two robots.
Ranges Supplied The element ranges of selected class and type inside the
current physical library.
The ranges already occupied with the partitions are shown in
gray, and the partition name is indicated. The ranges that are
free for the new partition are shown in black.
Update Click Save partition properties after edit.
