Scalar DLC Reference Guide 169
The not active LUN becomes active after a client (SCSI Client) assigned to it. Refer to SCSI Client on page
147.
Create Target
Under the SCSI Port properties, the Add new Target button appears (active for the enabled ports only).
Clicking it opens a pop-up target creation pane.
Figure 120 SCSI Target Creation
Note
The LUN 0 cannot be removed manually. It is deleted only with the Target.
Note
Because of interface properties, one and only one SCSI Client can be assigned to the
single LUN.
CAUTION
After the client is assigned to the LUN 0 of any target, all other clients
assigned to the non-zero LUNs of this target are activated.
Note
Only administrator users can create targets. For the user without administrative
privileges, the Add new Target button is disabled.
Field/Button Icon Operation Description
Target ID Supplied The target ID (internal).
Name Supplied The target name. Contains ‘Target’ and the SCSI ID.
SCSI ID Enter The target SCSI ID (external, seen by SCSI initiator).
SCSI Mode Select The target operating mode.
Only SCSI-2 and SCSI-3 are currently supported.
LUN Vendor ID Select Current target LUN 0 vendor ID.
LUN Product ID Select Current target LUN 0 product ID. The format of the
data transferred from/to the SCSI initiator.
