Scalar DLC Reference Guide 31
Screen Refresh Icon
The broad black bar containing the red ADIC logo is a screen refresh icon. It also contains the user-to-host
connection status (as at the example picture, User admin connected to computer, where admin is the user
name and computer is either the Scalar DLC host name or the Scalar DLC cluster name). This button
forces the Management GUI screen to refresh.
Connection
This section contains the basic Log off and Exit operations.
Icon Description
Refresh the Management GUI screen.
The black bar itself acts as the refresh button, too.
Note
Depending on the PC performance and the current Scalar DLC configuration, the refresh
may take up to several minutes.
Note
Some update (for example, library statistic) is not performed by the global refresh but
requires special refresh operarion initiated by an appropriate button.
Options Name Description
Log Off Log off the Management GUI. A new log on dialog appears.
Exit Close and exit the current applet or application and log off the user.
