Scalar DLC Reference Guide 17
Automatic Configuration
ADIC recommends the automatic configuration for typical or first time users. Using the automatic
configuration, create a default Scalar DLC configuration for each detected physical library.
The automatic configuration creates the configuration by executing the following procedures:
Step 1 Scans the SCSI bus for physical libraries.
Step 2 Creates partitions for all the physical library elements.
Step 3 Creates a logical library.
Step 4 Assigns all created partitions to the logical library making it a representation of the whole
physical library.
Step 5 For the logical library, creates two identical mailboxes (I01 and E01) that include all the mailbox
slots.
Step 6 Creates a client and assigns it to the logical library.
Partition 30 an, a first None (absent) None
(absent)
None
Client 80 an, a first 80 an, a first 80 an, a first None
Scratch pool 30 an, a first 16 an, a first None
(absent)
None
Clean pool 30 an, a first 16 an, a first Paa None
Data cartridge, volser 30 an 16 an (6
recommended)
6 an None
Cleaning cartridge,
volser
30 an 16 an (CL + 4 an
recommended)
CL + 4 an None
Mailbox area, eject
operations
30 an, a first 3 an, Enn
recommended
Enn None
Mailbox area, insert
operations
30 an, a first 3 an, Inn
recommended
Inn None
Drive 40 an, a first 30 an
b
(9 an, a first
recommended)
Dnn None
a. alphanumeric; “a” means “alpha” (A-Z), “n” means “numeric” (0-9).
b. Only for DAS ACI ver. 3.12 and higher.
Note
By default, if the DAS Client support is installed, the created client is the DAS Client; if
not, no client can be created because the SCSI and ROBAR interfaces need certain pre-
configuration.
Table 6 Object name limitations (Continued)
Object GUI Manager DAS / ACI ROBAR SCSI
