118 Configuration Tab
Robot
Depending on type, the physical library can have either one robotic controller (single-aisle library - Scalar
1000, Scalar 10K), or two (dual-aisle library, Scalar 10K DA).
Figure 86 Robot Online
Requests Supplied Requests received by physical library.
Refresh Click Refresh Physical Library statistics.
Help Click Open online help for the current pane.
Field/Button Icon Operation Description
Name Supplied Robotic controller name.
Number Supplied Robotic controller number (1 for single-aisle robot, 1 or
2 for dual-aisle robots).
State Supplied Robotic controller state. See Table 12
on page 64.
Barcode mode Supplied Barcode reader is always active for the Scalar robots.
Start Click Start the robot that is currently offline.
Field/Button Icon Operation Description
