Scalar DLC Reference Guide 283
ROBAR Coordinates
For all physical positions in the system, the Scalar DLC software provides a signification coordinate. With
the help of this coordinate, the Scalar DLC can compute the physical position. These are LSCI coordinates
(the Scalar DLC database contains a coordinate decoder and uses the LSCI coordinate system as well as
SCSI coordinates, and others). Refer to Element Addressing
on page 244.
Additionally, for the Insert/Eject unit, Drives, Jukebox, and Problem box, the ROBAR interface uses special
coordinates.
Table 44 ROBAR Coordinates
Area Description Example
Storage area typical LSCI coordinate - device, column, row, position 01010101 (device 1, column
1, row 1, position 1)
Insert area coordinate starts with 0001 followed by row and
position
00010510 (row 5, slot 10)
Eject area coordinate starts with 0002 followed by row and
position
00020608 (row 6, slot 08)
Foreign
Mount area
coordinate starts with 0003 followed by row and
position
00030701 (row 7, slot 01)
Drive/
Jukebox
coordinate starts with 0000 followed by the drive
address/name and 01
00000F01 (drive addr. 0F)
0000ZQ01 (drive name ZQ)
Problem box coordinate starts with 000000 followed by number of
the problem box
000000001 (problem box 1)
