The following tables describe the states and properties of the objects mentioned above.
Offline
cartridges
• Black This list indicates cartridges that were removed from the
physical library and their image is remained for archive
purposes.
Data
cartridge
• Dark green For a dark green cartridge text, the list indicates the data
cartridges. See Table 19
on page 78 for the details.
Cleaning
cartridge
•Dark
yellow
For a dark yellow cartridge text, the list indicates the cleaning
cartridges. See Table 19
on page 78 for the details.
Storage slots • Black This list indicates the storage area in the physical library.
Storage slot • Blue
•Gray
For a blue storage slot name, a cartridge is present in the slot.
See Table 14
on page 65.
•Black
•Gray
For a black storage slot name, the slot is empty. See Table 14
on page 65.
Mailbox • Black The name of the insert/eject area of the logical library.
Contains a set of insert/eject slots that are also called
mailboxes or mailbox slots.
The mailbox content may be either a continuous slot range or
a discrete set.
Mailboxes • Black This list indicates the whole mailbox (insert/eject) area in the
physical library.
Mailbox slot • Blue
•Gray
For a blue mailbox slot name, a cartridge is present in the slot.
See Table 15
on page 66.
•Black
•Gray
For a black mailbox slot name, the slot is empty. See Table 15
on page 66.
Drives • Black This area contains the drive slots for executing the read/write
operations
Drive slot • Blue
•Gray
For a blue drive slot name, a cartridge is present in the slot.
See Table 16
on page 67.
•Black
•Gray
For a black drive slot name, the slot is empty. See Table 16
on
page 67.
Table 10 Logical Library States
State Icon Color Description
Online Green The library is online and accepts all commands
Online, alarm
a
Green The library is online and accepts all commands.
An error has been encountered.
Table 9 Tree Objects (Continued)
Object Icon Color Description
