Scalar DLC Reference Guide 195
Operator Panel Tab
This tab mimics the operator panel on the actual device and provides an interactive path between the
operator and the library indicators and push-buttons that control the library.
Figure 138 Operator Panel Tab for the Scalar 10K
Logistics h. Supplied The time for administrative functions associated with the
repair. Parts ordering is an example of the logistics associated
with the repair.
Diagnostic h. Supplied The time to diagnose the problem.
Repair h. Supplied The time necessary to repair the problem.
Parts Usage Installed Supplied The total repair parts.
Support Diary Supplied Comments about the repair process.
OK Click Return to the ATAC Calls pane.
Note
The Scalar 10K DA library has two different robots and respectively two different
operator panels.
Field/Button Icon Operation Description
