6 Description
• 15" or greater SVGA Display
• NT/2000 compliant SCSI adapter
• Standard keyboard and mouse
• Windows 2000 SP4 or Windows 2003 pre-installed
Optional:
• SCSI target HBA LSI 20860, LSI 8751D, and/or LSI 8951U
• Fibre Channel target HBA QLogic 2200F-33 and/or QLogic 23xxF
Refer to Table 1
for a description of SCSI and Fibre Channel adapters that can be used in the system.
Redundant Solution Requirements
The Scalar DLC Redundant (failover) solution is provided using the Microsoft Cluster service. The user has
a shared disk with the Scalar DLC database and two hosts with the installed components of Scalar DLC
software; for redundancy reasons, one host is online and the other is offline. If an error occurs and the online
host goes offline, the other host turns online immediately, so the customer even does not notice a problem
with the host. The customer engineer can repair the problem host without stopping the Scalar DLC software.
The Scalar DLC Redundant solution is based on Microsoft Cluster service. The special requirements are:
• Two PCs, each meeting the standards described in PC System Requirements
on page 5.
• Microsoft Windows 2000 Advanced Server or Windows 2003 Server installed on each PC.
• Microsoft Cluster Service installed on each PC.
• For each PC, there should be a minimum of two disk controllers. The two disk controllers do not
need to be the same type. For example, using on-board IDE and SCSI is acceptable.
• At least one external (shared) RAID disk. The disk partition should have NTFS formatting.
• RAID adapter (on each PC) to access a shared disk.
Table 1 SCSI and Fibre Channel Adapters
Adapter Type Connection (external) Max cable length, m
LSI 20860 SCSI 50-pin high density SE 5
LSI 8751D SCSI 68-pin high density HVD 25
LSI 8951U SCSI 68-pin very high density LVD/SE 12(LVD), 5(SE)
QLA 2200 Fibre Channel SC duplex multi-mode -
QLA 23xx
a
a. ‘xx’ means 00, 10, 40, and 42. No other models are currently supported.
Fibre Channel Small form factor multi-mode optic LC -
Local
b
b. The driver is designed by ADIC to execute the SCSI backup applications right on the Scalar DLC server PC. No SCSI/FC
hardware is required.
SCSI - -
CAUTION
The Scalar DLC failover solution in a redundant configuration requires the
Windows 2000 Advanced Server or Windows 2003 Server operating system.
By default, this system is configured without password protection for network
access. So ADIC strongly urges companies using this product to use all
customary procedures to protect Scalar DLC servers from external threats.
