166 Configuration Tab
Target
In the Select Components area of the pane, selectable Targets appear.
Figure 118 SCSI Target
The not active Target becomes active after a client (SCSI Client) assigned to the LUN 0 of this target. Refer
to SCSI Client
on page 147.
Field/Button Icon Operation Description
Target ID Supplied The target ID (internal).
Name Supplied The target name. Contains ‘Target’ and the SCSI ID.
SCSI ID Supplied The target SCSI ID (external, seen by SCSI initiator).
SCSI Mode Supplied The target operating mode.
Only SCSI-2 and SCSI-3 are currently supported.
Also refer to Table 23
on page 163
Add new
LUN
Click Pop-up LUN creation window appears. Refer to Create LUN
on page 170.
Remove Click Remove the SCSI Target.
Help Click Open online help for the current pane.
