Quantum Scalar 1000 - Figure 5-30 Response Dialog; Figure 5-31 Response Screen; Figure 5-32 Response Screen

Status Menu 5-29
22 June 2004
Press the button to print the error log and the
Response Dialog appears. See Figure 5-30.
Figure 5-30 Response Dialog
Parameter Value
Continue Y to print the log to the serial
port.
N to not print the log to a serial
port.
If Y is selected for the Continue parameter value, the two
Response Screens appear. See Figure 5-31 and
Figure 5-32.
Otherwise, the changed parameter continues to display
but no action is taken.
Figure 5-31 Response Screen
Figure 5-32 Response Screen
The system is about
to print the log to
the serial port!
Continue: N<
Note
These screens
may flash by
quickly.
Requested command is
now in progress...
Requested command is
now complete...
