Commands Menu 5-43
22 June 2004
Inventory Dialog
Path: Main Menu Commands Menu Inventory Dialog
Use the Inventory Dialog to inventory specific elements.
See Figure 5-52.
Figure 5-52 Inventory Dialog
Parameter Value
Coord The first field indicates the
type of cell (I for I/E Station, D
for Drive, S for Storage cell).
The second field displays
module numbers that can be
modified if EMs are present (1–
4).
The third field indicates the
storage cell section (1–4), drive
bay (1–2), or IE station number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
The fifth field indicates the row
of the column.
(01–12 for ½-inch and
SDLT/DLT coordinates)
(01–14 for LTO coordinates)
(01–18 for AIT coordinates)
Element Displays the element number
that corresponds to the
coordinate parameter.
Accept Y to accept changes
N to reject changes
Starting Inventory
Coord: S 02 1< A 01
OR Element: 00000
Accept : N
