Status Menu 5-15
22 June 2004
Element Address
Use Element Address to check current, default, or saved
addresses of the Accessor, storage cell, I/E station, or tape
drives. See Figure 5-11.
Figure 5-11 Element Address Screen
Parameter Value
Base MT Current, default, or saved base
Accessor address
Base ST Current, default, or saved base
Storage Cell address
Base IE Current, default, or saved base
Insert/Eject station address
Base DT Current, default, or saved base
tape drive address
Mixed-Media Support
Use Mixed-Media Support to see barcode processing or if
the read element, unique additional sense code qualifier, or
mixed mode is enabled.
When Mixed-Media Support is selected, the Mixed-Media
screen appears. See Figure 5-12.
Figure 5-12 Mixed-Media Screen
Base MT : 00001
Base ST : 04096
Base IE : 00016
Base DT : 00256
MediaID :N Mixed: N
Ext RES : N
Ext ASCQ : N
Ext BC : N
To Next Page
