Service Menu 5-131
22 June 2004
X Indicates the returned
horizontal position value of
the scanner (it should be 0267.0
± 0.2).
Press this button to select X or
Y.
Trigger Dialog
Path: Main Menu Service Menu Diags
Submenu Scanner Submenu Trigger Dialog
Use the Trigger Dialog to trigger the barcode scanner to
read, decode, and display whichever barcode label is within
the range of the beam. See Figure 5-180.
Figure 5-180 Trigger Dialog
Parameter Value
BC Returns the barcode label
information for the storage
cartridge.
Note
Do not use the up
or down arrows
to change gripper
positions because
scanner
adjustment will
be invalid.
SCANNER TRIGGER
Pressing Enter will
trigger scanner
BC :000389
