Quantum Scalar 1000 - IP Dialog

5-88 Menus and Commands
6-00054-02 Rev A
IP Dialog
Path: Main Menu Setup Menu Library
Submenu RMU Submenu IP Dialog
Use the
IP Dialog to set the IP, Subnet, and Gateway
network addresses for RMU library communication.
See Figure 5-118.
Figure 5-118 IP Dialog
Parameter Value
IP Indicates the IP address (four
sets of numbers 0–255).
Sub Indicates the Subnet address
(four sets of numbers 0–255).
Gat Indicates the Gateway (four
sets of numbers 0–255).
Accept Y to accept changes
N to reject changes
If Y is selected for the Accept parameter value, the screen
updates to reflect the changes. Otherwise, the changed
parameters continue to display but no action is taken.
IP : 100<100.100.100
Sub: 255.255.255.255
Gat: 100.100.100.100
Accept: N
