Status Menu 5-23
22 June 2004
Parameter Value
Coord The first field indicates the
type of cell (I for I/E Station, D
for Drive, S for Storage cell).
The second field displays
module numbers that can be
modified if EMs are present (1–
4).
The third field indicates the
storage cell section (1–4), drive
bay (1–2), or IE station number.
The fourth field indicates the
column of the section (A–E),
drive port (A–B), or IE station
column.
The fifth field indicates the row
of the column.
(01–12 for ½-inch and SDLT/
DLT coordinates)
(01–14 for LTO coordinates)
(01–18 for AIT coordinates)
Element Displays the element number
that corresponds to the
coordinate parameter.
Accept Y to accept changes
N to reject changes
If Y is selected for the Accept parameter value, the
Response Dialog appears. See Figure 5-21. Otherwise,
the changed parameters continue to display but no action
is taken.
Figure 5-21 Response Dialog
Status: Full
BC : 0000000000000345
Source: 0100
Valid : Yes [more]
