5-130 Menus and Commands
6-00054-02 Rev A
Scanner Submenu
Path: Main Menu Service Menu Diags
Submenu Scanner Submenu
Use the Scanner Submenu to adjust and test the barcode
scanner. See Figure 5-178.
Figure 5-178 Scanner Submenu
Depending on your selection, one of the following appears:
• Adjust Dialog on page 5-130
• Trigger Dialog on page 5-131
• Fiducial Test Dialog on page 5-132
Adjust Dialog
Path: Main Menu Service Menu Diags
Submenu Scanner Submenu Adjust Dialog
Use the Adjust Dialog to position the barcode scanner
beam over a specific location to adjust the beam. This function
should be used only by trained service personnel. See
Figure 5-179. Refer to the Scalar 1000 Maintenance Guide for the
step by step procedure to adjust the scanner.
Figure 5-179 Adjust Dialog
Parameter Value
Y Indicates the returned vertical
position value of the scanner
(it should be 1005.0 ± 0.2).
>Adjust...
Trigger...
Fiducial Test...
DIAGS SCANNER ADJUST
Adjust scanner until
beam is level.
Y: 1005.0< X:0267.0
