5-122 Menus and Commands
6-00054-02 Rev A
Get/Put Storage Dialog
Path: Main Menu Service Menu Diags
Submenu Gripper Submenu Get/Put Storage
Dialog
Use the Get/Put Storage Dialog to start Get and Put of
all cartridges in a specified range. No element-to-element
movements take place. See Figure 5-168.
Figure 5-168 Get/Put Storage Dialog
Parameter Value
Cycles to run Indicates the number of cycles
to run (1–999)
[more] More selections on the
Continuation Menu
When [more] is selected, the Continuation Screen
appears. See Figure 5-169.
Figure 5-169 Continuation Dialog
Parameter Value
Coord The first field indicates the
type of cell (I for I/E Station, D
for Drive, S for Storage cell).
The second field displays
module numbers that can be
modified if EMs are present
(1–4).
The gripper test will
get/put media
Cycles to run: 009<
[more]
Enter SOURCE
Coord: S 01< 2 A 01
OR Element: 00000
Accept: N
